High quality 3003 Aluminium Plate / Aluminum Sheet

High quality 3003 Aluminium Plate / Aluminum Sheet Featured Image

Short Description:

FOB Price: US $6 / Ton

Supply Ability: 10000 Tons per Month

Port: ShangHai

Payment Terms: L/C,D/A,D/P,T/T

Grade: 1000 Series

Place of Origin: Shanghai, China (Mainland)

Sample: Avaliable

Application: Decoration/Construction

Packaging: Wooden Pallet or Box

Send email to us Download as PDF

Product Detail

Product Tags

GB/T 3190	ISO 2092	ASTM B221	JIS H4040
1060	Al99.6	1060	1070
1100	Al99.0Cu	1100	1100
2024	AlCu4Mg1	2024	2024
3003	AlMn1Cu	3003	3003
5052	AlMg2.5	5052	5052
5083	AlMg4.5-Mn0.7	5083	5083
6061	AlMg1SiCu	6061	6061
7075	AlZn5.5-CuMg	7075	7075

GB/T 3190	Chemical Composition(%)
GB/T 3190	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Al
1060	0.25	0.35	0.05	0.03	0.03	-	0.05	0.03	99.6
1100	0.95 Si+Fe		0.05-0.20	0.05	-	-	0.1	-	99
2024	0.5	0.5	3.8-4.9	0.3-0.9	1.2-1.8	0.1	0.25	0.15	Balance
3003	0.6	0.7	0.05-0.20	1.0-1.5	-	-	0.1	-	Balance
5052	0.25	0.4	0.1	0.1	2.2-2.8	0.15-0.35	0.1	-	Balance
5083	0.4	0.4	0.1	0.40-1.0	4.0-4.9	0.05-0.25	0.25	0.15	Balance
6061	0.40-0.8	0.7	0.15-0.40	0.15	0.8-1.2	0.04-0.35	0.25	0.15	Balance
7075	0.4	0.5	1.2-2.0	0.3	2.1-2.9	0.18-0.28	5.1-6.1	0.2	Balance

Grade	Temper	Thickness/mm	Tensile Strength Rm/MPa	Extension Strength Rp0.2/MPa	Elongation/ %		Bending Radius
		Thickness/mm	Tensile Strength Rm/MPa	Extension Strength Rp0.2/MPa	A50mm	A5.65	Bending Radius
		more than	no less than
3003	0	0.20-0.50	95-140	35	15	－	0t
		0.50-1.50			17	－	0t
		1.50-3.00			20	－	0t
		3.00-6.00			23	－	1.0t
		6.00-12.50			24	－	1.5t
		12.50-50.00			－	23	－
	H12	0.20-0.50	120-160	90	3	－	0t
		0.50-1.50			4	－	0.5t
		1.50-3.00			5	－	1.0t
		3.00-6.00			6	－	1.0t
	H14	0.20-0.50	145-195	125	2	－	0.5t
		0.50-1.50			2	－	1.0t
		1.50-3.00			3	－	1.0t
		3.00-6.00			4	－	2.0t
	H16	0.20-0.50	170-210	150	1	－	1.0t
		0.50-1.50			2	－	1.5t
		1.50-4.00			2	－	2.0t
	H18	0.20-0.50	190	170	1	－	1.5t
		0.50-1.50			2	－	2.5t
		1.50-4.00			2	－	3.0t
	H22	0.20-0.50	120-160	80	6	－	0t
		0.50-1.50			7	－	0.5t
		1.50-3.00			8	－	1.0t
		3.00-6.00			9	－	1.0t
	H24	0.20-0.50	145-195	115	4	－	0.5t
		0.50-1.50			4	－	1.0t
		1.50-3.00			5	－	1.0t
		3.00-6.00			6	－	2.0t
	H26	0.20-0.50	170-210	140	2	－	1.0t
		0.50-1.50			3	－	1.5t
		1.50-4.00			3	－	2.0t
	H28	0.20-0.50	190	160	2	－	1.5t
		0.50-1.50			2	－	2.5t
		1.50-3.00			3	－	3.0t
	H112	6.00-12.50	115	70	10	－
	H112	12.50-80.00	100	40	－	18	－
	F	－	2.50-150.00	－			－
