| Grade | Chemical composition（%）≤ | Thickness (mm) |
||||
| GB | ASTM | Cu | Cr | Zr | Si | |
| TCr0.3-0.15-0.03 | C18140 | Balance | 0.15-0.45 | 0.05-0.25 | 0.005-0.05 | 0.06-5.0 |
| Physical properties | ||||||
| Density (g/cm³) |
Modulus of elasticity (GPa) |
Thermal expansion coefficient (×10-6/K) |
Electrical conductivity (%IACS) |
Thermal conductivity W(m·K) |
||
| 8.9 | 135 | 18.6 | 85 | 330 | ||
| Mechanical properties | Bend properties | |||||
| Temper | Hardness HV |
Tension test | 90°R/T(Thick＜0.5mm) | |||
| Tensile Strength Rm/MPa |
Yield Strength MPa |
Elongation % |
Good way | Bad way | ||
| R460 | 120-180 | 475-575 | 430-530 | ≥8 | 0 | 1 |
| R540 | 140-200 | 525-625 | 500-600 | ≥6 | 0 | 2 |
| R580 | 160-220 | 575-725 | 530-705 | ≥4 | - | - |
