| GB | ISO | ASTM | JIS | ||
| TU1 | Cu-OF | C10200 | C1020 | ||
| T2 | Cu-ETP | C11000 | C1100 | ||
| TP1 | Cu-DLP | C12000 | C1201 | ||
| TP2 | Cu-DHP | C12200 | C1220 | ||
| GB | Composition(%) | ||||
| Cu | P | O | Other | ||
| TU1 | 99.97 | 0.002 | less than 0.002 | balance | |
| TU2 | 99.95 | 0.002 | less than 0.003 | balance | |
| T2 | 99.9 | － | - | balance | |
| TP1 | 99.9 | 0.004-0.012 | - | balance | |
| TP2 | 99.9 | 0.015-0.040 | - | balance | |
| ASTM | Composition(%) | ||||
| Cu+Ag | P | O | Other | ||
| C10200 | 99.95 | 0.001-0.005 | - | balance | |
| C10300 | 99.95 | 0.001-0.005 | - | balance | |
| C11000 | 99.9 | – | - | balance | |
| C12000 | 99.9 | 0.004-0.012 | - | balance | |
| C12200 | 99.9 | 0.015-0.040 | - | balance | |
| Grade | Temper | Thickness /mm | Tensile Strength Rm/MPa |
Elongation A11.2/% |
HV |
| T2 TP1 TP2 TU1 |
M20 | 4-14 | no less than 195 | no less than 30 | － |
| O60 | 0.3-10 | no less than 205 | no less than 30 | no more than 70 | |
| H01 | 215-295 | no less than 25 | 60-95 | ||
| H02 | 245-345 | no less than 8 | 80-110 | ||
| H04 | 295-395 | － | 90-120 | ||
| H06 | no less than 350 | － | no less than 110 |
